220V 50Hz Horizontal Flow Wrapping Machine Compact Flow Wrapping Equipment

Applicable to packaging of special-shaped metal hardware, plastic products, electrical appliances, stationery, multi-pack combinations and other small-sized goods.

1. Sealing cutter mechanism: Rotary type, single cutter and single heating tube with 132mm center distance. Straight grain design, 3-stripe coarse tooth cutter seat with 230mm length, surface treated with Teflon coating.
2. Center sealing mechanism: Large roller pressing and small roller paper pulling, Teflon coated surface. Vertical grain paper pulling roller with 10mm width; rice pattern pressing roller with 10mm pressing width. Standard equipped with lower center sealing conveyor and green PVC belt.
3. Paper feeding swing rod mechanism: Basic structure with standard fine paper feeding adjustment function.
4. Paper supporting mechanism: Standard independent single support.
5. Tail frame: Belt feeding tail frame with 2m length. Non-food grade green PVC belt applied. Movable side panels: 180mm in width, 25mm in height.
6. Bag former: Standard adjustable bag former, maximum adjustable width 160mm.
7. Discharge part: Standard green PVC belt with 340mm length.
8. Carbon steel frame with black finish; sealing cutter shield made of black ABS polymer material.
9. 7-inch touch screen equipped.

1. Performance Features:
   1. The entire machine is controlled by three high-performance servo motors, ensuring stable operation and precise control.
   2. Rotary cross-sealing system with independent servo drive for enhanced sealing accuracy and efficiency.
   3. Vertical sealing, film feeding, and product discharge are each controlled by independent servo motors for improved synchronization and reliability.
   4. Tail conveyor system driven by an independent servo motor for smooth and precise product transfer.
   5. Equipped with a 7-inch color touchscreen human-machine interface (HMI) for easy operation and parameter management.
   6. Wide packaging capability, compatible with a variety of product sizes and packaging requirements.
   7. Multiple product parameter storage functions enable quick and convenient specification changes.
   8. Integrated counting and photoelectric detection systems with automatic bag length tracking and adjustment, eliminating the need for manual settings.
   9. High overall operating precision with accurate sealing and cutting positioning.
   10. Stop position and coding position can be freely adjusted via the touchscreen with simple one-touch operation.
   11. Simple mechanical design, easy commissioning, intuitive operation, and low maintenance costs..
