8000 - 9000 Bottles/Hour Automatic Labeling Machine Different Conveyor Systems Bottle Labelling Machine

Certification : VERIFICATION OF CONFORMITY

Speed : 254mm/sec

Operator : 1 set/person

Feature : High Stability

MOQ : 1 set

Applicable Label Range : length 10 ~ 260mm, width 10-155mm

Capacity : 8000-9000 bottles per hour

Place of Origin : CHINA

Safetyfeatures : Emergency stop button, safety guards

Label Speed : 20-50bottles/min

Model Number : ZRD-220

Price : Negotiable

Name : Automatic Labeling Machine

Brand Name : ZHIROBO

Delivery Time : 15-30 working days

Payment Terms : T/T

Contact Now

Automatic Labeling Machine Compatible with Different Conveyor Systems to Facilitate Smooth Product Handling and Labeling
Basic Use

Mainly used for laser coding and rewinding of various coiled materials.

Equipment Advantages
  • Human-machine interface with microcomputer programmable control.
  • Equipped with three-servo control system. Servo motors control rewinding and unwinding tension to ensure stable and reliable material tension; servo positioning film feeding with adjustable length.
  • Adopts high-precision water-cooled ultraviolet laser.
  • Adjustable coding quantity for products.
  • Easy operation, automatic fault alarm and one-key intelligent operation.

Equipment Layout

8000 - 9000 Bottles/Hour Automatic Labeling Machine Different Conveyor Systems Bottle Labelling Machine

Main Technical Parameters
Model ZRD-220 Rewinding Coding Machine
Material Width 50-220mm
Material Diameter Max outer diameter: 245mm (core diameter: 76mm)
Coding Speed Depends on coding requirements
Mechanical Allowable Speed 0-30m/min
Laser Type 10W UV Laser (355nm)
Voltage and Power AC220V 2.6KW
Air Pressure 0.5mpa
Machine Dimensions 1620mm*1380mm*1750mm
Net Weight 1600KG
Configuration Parameters
Model Rewinding Coding Machine ZRD-220
Touch Screen HMI
Servo Roll Feed HCFA
Roll Feeding Driver HCFA
Fixed-length Servo HCFA
Fixed-length Driver HCFA
Rewinding Servo HCFA
Rewinding Driver HCFA
Laser Coding Machine KEXIN
Laser Galvo Scanner KEXIN
Reducer Smart
Detection Fiber KEYENCE
PLC HCFA
Air Switch CHINT
Switching Power Supply MEAN WELL
Deviation Correction Youdao
Relay IDEC
Push Button Switch Schneider
Cylinder XINGCHEN
Filter STNC
Solenoid Valve STNC
Magnetic Switch AirTAC
Bearing NSK
Frame Imported Powder Coating
Motion Controller HCFA
Photoelectric Sensor Boyee
Guide Rail HIWIN

8000 - 9000 Bottles/Hour Automatic Labeling Machine Different Conveyor Systems Bottle Labelling Machine

8000 - 9000 Bottles/Hour Automatic Labeling Machine Different Conveyor Systems Bottle Labelling Machine
